NEMA G5 and G9 Sheets Glass Reinforced Melamine

G5 Phenolic Sheets

NEMA G5, G9 Sheets Glass Reinforced Melamine - natural (grayish brown) Technical Data Sheet
This grade is composed of a continuous glass woven cloth base impregnated with a melamine resin binder. Melamines are the hardest of all laminates, exhibiting good dimensional stability and arc resistance. It is also caustic resistant.



NEMA G-5 MIL-I-24768/8 GMG , IEC 60893-3 Type 3 MF GC 201

NEMA G-9 MIL-I-24768/1 GME, IEC 60893-3 Type 3 MF GC 201



NEMA G5, G9 Sheets and Plates
Stock # / Image Thickness Inches Width Inches Length Inches  Price Purchase Online
KS-5863 .031 12 12 $27.78 4 Sheet Min
KS-1938 .063 12 12 $41.13 Buy Now
KS-1945 .094 12 12 $31.85 Buy Now
KS-1952 .125 12 12 $86.98 Buy Now
KS-1959 .188 12 12 $97.55 Buy Now
KS-1966 .250 12 12 $144.39 Buy Now
KS-1973 .313 12 12 $139.47 Buy Now
KS-1980 .375 12 12 $167.67 Buy Now
KS-1988 .500 12 12 $186.25 Buy Now
KS-1995 .625 12 12 $191.84 Buy Now
KS-2002 .750 12 12 $223.23 Buy Now
KS-2009 .875 12 12 $254.59 Buy Now
KS-2016 1.000 12 12 $285.95 Buy Now
KS-2023 1.250 12 12 $356.55 Buy Now
KS-2030 1.500 12 12 $420.84 Buy Now
KS-2037 2.000 12 12 $549.47 Buy Now
KS-5871 .031 12 24 $49.26 2 Sheet Min
KS-1939 .063 12 24 $56.37 Buy Now
KS-1946 .094 12 24 $68.57 Buy Now
KS-1953 .125 12 24 $110.37 Buy Now
KS-1960 .188 12 24 $165.03 Buy Now
KS-1967 .250 12 24 $220.65 Buy Now
KS-1974 .313 12 24 $275.43 Buy Now
KS-1982 .375 12 24 $331.05 Buy Now
KS-1989 .500 12 24 $441.27 Buy Now
KS-1996 .625 12 24 $458.07 Buy Now
KS-2003 .750 12 24 $487.77 Buy Now
KS-2010 .875 12 24 $587.07 Buy Now
KS-2017 1.000 12 24 $694.77 Buy Now
KS-2024 1.250 12 24 $812.88 Buy Now
KS-2031 1.500 12 24 $937.74 Buy Now
KS-2038 2.000 12 24 $1223.07 Buy Now
KS-1940 .063 12 36 $53.52 Buy Now
KS-1947 .094 12 36 $77.52 Buy Now
KS-1954 .125 12 36 $105.72 Buy Now
KS-1961 .188 12 36 $158.13 Buy Now
KS-1968 .250 12 36 $211.38 Buy Now
KS-1975 .313 12 36 $263.79 Buy Now
KS-1983 .375 12 36 $317.04 Buy Now
KS-1990 .500 12 36 $422.76 Buy Now
KS-1997 .625 12 36 $528.48 Buy Now
KS-2004 .750 12 36 $634.14 Buy Now
KS-2011 .875 12 36 $739.80 Buy Now
KS-2018 1.000 12 36 $845.52 Buy Now
KS-2025 1.250 12 36 $1004.06 Buy Now
KS-2032 1.500 12 36 $1268.28 Buy Now
KS-2039 2.000 12 36 $1578.30 Buy Now
KS-1941 .063 12 48 $82.67 Buy Now
KS-1948 .094 12 48 $119.74 Buy Now
KS-1955 .125 12 48 $164.05 Buy Now
KS-1962 .188 12 48 $245.42 Buy Now
KS-1969 .250 12 48 $328.13 Buy Now
KS-1976 .313 12 48 $409.47 Buy Now
KS-1984 .375 12 48 $421.86 Buy Now
KS-1991 .500 12 48 $656.22 Buy Now
KS-1998 .625 12 48 $703.05 Buy Now
KS-2005 .750 12 48 $843.69 Buy Now
KS-2012A .875 12 48 $935.09 Buy Now
KS-2019 1.000 12 48 $1031.17 Buy Now
KS-2026 1.250 12 48 $1288.98 Buy Now
KS-2033 1.500 12 48 $1406.15 Buy Now
KS-2040 2.000 12 48 $2099.83 Buy Now
KS-5879 .031 24 24 $72.36
KS-1942 .063 24 24 $144.80 Buy Now
KS-1949 .094 24 24 $152.81 Buy Now
KS-1956 .125 24 24 $225.69 Buy Now
KS-1963 .188 24 24 $409.56 Buy Now
KS-1970 .250 24 24 $439.32 Buy Now
KS-1977 .313 24 24 $694.45 Buy Now
KS-1985 .375 24 24 $751.80 Buy Now
KS-1992 .500 24 24 $1095.15 Buy Now
KS-1999 .625 24 24 $1109.55 Buy Now
KS-2006 .750 24 24 $1100.37 Buy Now
KS-2013A .875 24 24 $1283.76 Buy Now
KS-2020 1.000 24 24 $1467.15 Buy Now
KS-2027 1.250 24 24 $1833.93 Buy Now
KS-2034 1.500 24 24 $2200.71 Buy Now
KS-2041 2.000 24 24 $2934.30 Buy Now
KS-5887 .031 24 36 $117.09 Buy Now
KS-1943 .063 24 36 $164.07 Buy Now
KS-1950 .094 24 36 $244.13 Buy Now
KS-1957 .125 24 36 $332.37 Buy Now
KS-1964 .188 24 36 $497.13 Buy Now
KS-1971 .250 24 36 $664.59 Buy Now
KS-1978 .313 24 36 $829.44 Buy Now
KS-1986 .375 24 36 $996.99 Buy Now
KS-1993 .500 24 36 $1329.33 Buy Now
KS-2000 .625 24 36 $1575.00 Buy Now
KS-2007 .750 24 36 $1852.14 Buy Now
KS-2014 .875 24 36 $2060.79 Buy Now
KS-2021 1.000 24 36 $2269.50 Buy Now
KS-2028 1.250 24 36 $2686.92 Buy Now
KS-2035 1.500 24 36 $3104.28 Buy Now
KS-2042 2.000 24 36 $3645.27 Buy Now
KS-1944 .063 24 48 $207.69 Buy Now
KS-1951 .094 24 48 $300.90 Buy Now
KS-1958 .125 24 48 $425.71 Buy Now
KS-1965 .188 24 48 $636.86 Buy Now
KS-1972 .250 24 48 $851.45 Buy Now
KS-1979 .313 24 48 $1062.57 Buy Now
KS-1987 .375 24 48 $1277.12 Buy Now
KS-1994 .500 24 48 $1459.56 Buy Now
KS-2001 .625 24 48 $1824.45 Buy Now
KS-2008 .750 24 48 $2189.37 Buy Now
KS-2015 .875 24 48 $2554.26 Buy Now
KS-2022 1.000 24 48 $2919.12 Buy Now
KS-2029 1.250 24 48 $3040.78 Buy Now
KS-2036 1.500 24 48 $3648.93 Buy Now
KS-2043 2.000 24 48 $4865.23 Buy Now
KS-5685 .010 36 48 $115.95 2 Sheet Min  Buy Now
KS-5686 .015 36 48 $122.91 2 Sheet Min  Buy Now
KS-5687 .020 36 48 $138.36 2 Sheet Min  Buy Now
KS-5708 .031 36 48 $185.19 Buy Now
KS-5709 .047 36 48 $225.21  Buy Now
KS-5710 .062 36 48 $258.81 Buy Now
KS-5972 .094 36 48 $388.20 Buy Now
KS-5897 .125 36 48 $521.82 Buy Now
KS-5973 .156 36 48 $651.21 Buy Now
KS-5898 .188 36 48 $780.60 Buy Now
KS-5899 .250 36 48 $1043.61 Buy Now
KS-5900 .313 36 48 $1239.42 Buy Now
KS-5901 .375 36 48 $1565.43 Buy Now
KS-5974 .438 36 48 $1824.21 Custom Order  Buy Now
KS-5975 .500 36 48 $2087.19  Buy Now
KS-5976 .625 36 48 $2609.04  Buy Now
KS-5977 .750 36 48 $3130.83  Buy Now
KS-5978 .875 36 48 $3652.62  Buy Now
KS-5979 1.00 36 48 $4174.44  Buy Now
KS-5980 1.25 36 48 $4783.19  Buy Now
KS-5981 1.50 36 48 $5739.38  Buy Now
KS-5625CE 1.75 36 48 $7305.18 Special Order
KS-5982 2.00 36 48 $7374.84  Buy Now
KS-5983 2.50 36 48 $9392.45  Buy Now
KS-5984 3.00 36 48 $5380.90  Buy Now







Tolerances for Sheet Thickness Inches

.010-.030 +/- .004"

.031 +/- .005"

.062 +/- .0075"

.093 +/- .009"

.125 +/- .012"

.156 +/- .015"

.188 +/- .019"

.250 +/- .022"

.313 +/- .026"

.375 +/- .030"

.438 +/- .033"

.500 +/- .036"

.625 +/- .040"

.750 +/- .043"

.875 +/- .046"

1.00 +/- .049"

1.25 +/- .055"

1.50 +/- .061"

1.75 +/- .065"

2.00 +/- .067"

2.50 +/- .075"
