NEMA G5 and G9 Glass Reinforced Melamine Tubes - .031" Wall

G5 G9 Tubes 1/32" Wall Thickness

NEMA G5, G9 Glass Reinforced Melamine - natural (grayish brown) Technical Data Sheet
This grade is composed of a continuous glass woven cloth base impregnated with a melamine resin binder. Melamines are the hardest of all laminates, exhibiting good dimensional stability and arc resistance. It is also caustic resistant.
Certifies to Mil-I-24768/1 GME    Chemical Resistance Chart

NEMA grades G5 and G9 Glass-Cloth Reinforced Melamine -- natural color is typically a grayish brown. These grades are composed of a continuous glass woven cloth base impregnated with a melamine resin binder. (Melamine resins, once cured, are the hardest, most rigid and abrasion resistant of the standard resins employed in the production of industrial laminates. However, prolonged exposure to high temperature can adversely affect its mechanical and electrical strength properties. Arc resistance, however, may remain unaffected despite excessive thermal exposure.) Melamines are the hardest of laminates, exhibiting good dimensional stability and arc resistance. It's also caustic resistant. A key difference between NEMA Grades G5 and G9 are that G9 is more resistant to the elements of the environment. Thus, G9 can be safely substituted where G5 is called for.

NEMA G-5 MIL-I-24768/8 GMG , IEC 60893-3 Type 3 MF GC 201

NEMA G-9 MIL-I-24768/1 GME, IEC 60893-3 Type 3 MF GC 201



NEMA G5/G9 Tube Tubes Wall Thickness Options

.031" .062" .093" .125"
.187" .250" .375" .500"
.750" 1.00" G5/G9 Sheets G5/G9 Rods



NEMA G5 and G9 Tubes - .031" Wall
Stock # / Image OD Inches ID Inches Min. Ft to Purchase Price/Ft Purchase Online
KM-1611 .250 .187 21 $30.00 Buy Now
KM-1615 .313 .250 21 $33.17 Buy Now
KM-1619 .375 .312 18 $35.28 Buy Now
KM-1623 .438 .375 18 $36.26 Buy Now
KM-1627 .500 .437 18 $37.26 Buy Now
KM-1631 .563 .500 24 $26.06 Buy Now
KM-1637 .625 .562 24 $26.91 Buy Now
KM-1646 .688 .625 24 $27.59 Buy Now
KM-1652 .750 .687 24 $28.58 Buy Now
KM-1655 .813 .750 33 $18.41 Buy Now
KM-20643 .875 .812 33 $18.72 Buy Now
KM-1661 .938 .875 33 $19.97 Buy Now
KM-20641 1.000 .937 33 $20.16 Buy Now
KM-1667 1.063 1.00 33 $20.48 Buy Now
KM-20639 1.125 1.062 30 $21.24 Buy Now
KM-20638 1.187 1.125 30 $21.92 Buy Now
KM-20637 1.250 1.187 30 $22.55 Buy Now
KM-20636 1.312 1.250 27 $23.09 Buy Now
KM-20635 1.375 1.312 27 $23.58 Buy Now
KM-20634 1.437 1.375 27 $24.08 Buy Now
KM-20528 1.500 1.437 27 $24.44 Buy Now
KM-20668 1.562 1.500 27 $25.11 Buy Now
KM-20523 1.625 1.562 24 $25.79 Buy Now
KM-20522 1.688 1.625 24 $26.42 Buy Now
KM-20521 1.750 1.687 24 $27.00 Buy Now
KM-20520 1.812 1.750 24 $27.59 Buy Now
KM-20519 1.875 1.812 24 $28.13 Buy Now
KM-20490 1.937 1.875 24 $28.62 Buy Now
KM-20462 2.000 1.937 21 $29.12 Buy Now







nominal inches,
diameter

plus or minus tolerance, inches

ID inside diameter

OD outside diameter

steel
mandrel

built-up
mandrel

.125" -.749"

.003"

-

.005"

.750" - 1.999"

.004"

-

.005"

2.000" - 4.000"

.006"

-

.008"



*turned

*as wound

4.001" - 12.000"

.010"

-

.025"

plus only

12.001" - 18.000"

.030"

.060"

.030"

plus only

18.001" - 24.000"

.040"

.075"

.035"

plus only

24.001" - 48.000"

.060"

.090"

.040"

plus only

*Note: tubing over 8.000" OD supplied as wound (turned OD quoted on request)
