NEMA G7 Glass Reinforced Silicone Rods

G7 Phenolic Rods

NEMA G7 Glass Reinforced Silicone Rods - natural (cream to white)

Technical Data Sheet
Composed of a continuous glass woven cloth base impregnated with a silicone resin binder, this grade has excellent heat and arc resistance. It has extremely good dielectric loss properties under dry conditions and good electrical properties under humid conditions, although the percentage of change is high.
NEMA G-7 MIL-I-24768/17 GSG, IEC 60893-3 Type 6 SI GC 201



NEMA G7 Rods

4 Ft. Standard Lengths, lead times may apply on some diameters.

Stock # / Image Diameter Inches Price/Ft. Purchase Online
KR-1277

.125"

$7.90 Buy Now
KR-1278

.187"

$10.42 Buy Now
KR-1279

.250"

$14.04 Buy Now
KR-1280

.312"

$18.74 Buy Now
KR-1281

.375"

$21.85 Buy Now
KR-1282

.437"

$26.69 Buy Now
KR-1283

.500"

$33.53 Buy Now
KR-2909 .563" $41.38 Buy Now
KR-1284

.625"

$56.31 Buy Now
KR-1285

.750"

$63.14 Buy Now
KR-1285X .875 $80.15 Special Order
KR-1286

1.000"

$96.10 Buy Now
KR-1287

1.250"

$157.97 Buy Now
KR-1288

1.500"

$215.71 Buy Now
Tolerances

Under 1.375" Dia.

+/- .001"

1.375" Dia. & Over

+/- .003"
