Canvas C/CE Fabric Reinforced Phenolic - .093" Wall Thickness
Canvas C/CE Fabric Reinforced Phenolic - natural
(light tan to brown) Technical
Data Sheet
This grade is composed of a continuous woven cloth
impregnated with a phenolic resin binder. This grade contains a medium weave
canvas and is known primarily for it's mechanical properties. This grade is not
recommended for primary insulation.
NEMA grades C, and CE Canvas
Cotton-Cloth Reinforced Phenolic -- natural color is typically light tan to
brown. C and CE grades are composed of a continuous woven cloth
impregnated with a phenolic resin binder. These grades contain a medium weave
canvas and are known primarily for their mechanical properties. These grades are
not recommended for primary electrical insulation. (Grade C certifies to Mil-I-13768/16 FBM, IEC 60893-3 Type 4, PF CC 201)
(Grade CE certifies to Mil-I-24768/14 FBG, IEC 60893-3 Type 4, PF CC 203)
C/CE Tubes C/CE Sheets C/CE Bar Stock
| .093" Wall Thickness - CE Tubes | |||||
| Stock # | OD Inches | ID Inches | Min. Feet to Purchase | Price Per Foot | Purchase Online |
| KM-2002 | .375 | .187 | 12 | $7.93 | Buy Now |
| KM-2006 | .438 | .250 | 9 | $8.58 | Buy Now |
| KM-2010 | .500 | .312 | 9 | $8.85 | Buy Now |
| KM-2018 | .625 | .437 | 33 | $10.08 | Buy Now |
| KM-2014 | .656 | .375 | 6 | $10.15 | Buy Now |
| KM-2022 | .688 | .500 | 51 | $6.93 | Buy Now |
| KM-18241 | .750 | .562 | 51 | $7.13 | Buy Now |
| KM-2033 | .813 | .625 | 48 | $7.25 | Buy Now |
| KM-18239 | .875 | .687 | 48 | $7.88 | Buy Now |
| KM-2042 | .938 | .750 | 45 | $8.13 | Buy Now |
| KM-18237 | 1.000 | .812 | 42 | $8.58 | Buy Now |
| KM-2047 | 1.063 | .875 | 39 | $8.88 | Buy Now |
| KM-18235 | 1.125 | .937 | 36 | $9.38 | Buy Now |
| KM-2053 | 1.187 | 1.000 | 36 | $9.88 | Buy Now |
| KM-18233 | 1.250 | 1.062 | 36 | $10.35 | Buy Now |
| KM-18242 | 1.312 | 1.125 | 36 | $10.83 | Buy Now |
| KM-18231 | 1.375 | 1.187 | 33 | $11.30 | Buy Now |
| KM-18230 | 1.437 | 1.250 | 30 | $11.75 | Buy Now |
| KM-18229 | 1.500 | 1.312 | 30 | $12.23 | Buy Now |
| KM-18228 | 1.562 | 1.375 | 30 | $12.65 | Buy Now |
| KM-18227 | 1.625 | 1.437 | 27 | $13.10 | Buy Now |
| KM-18226 | 1.688 | 1.500 | 27 | $13.53 | Buy Now |
| KM-18296 | 1.750 | 1.562 | 27 | $13.93 | Buy Now |
| KM-18352 | 1.812 | 1.625 | 24 | $14.35 | Buy Now |
| KM-18262 | 1.875 | 1.687 | 24 | $14.75 | Buy Now |
| KM-18332 | 1.937 | 1.750 | 24 | $15.13 | Buy Now |
| KM-18331 | 2.000 | 1.812 | 24 | $15.53 | Buy Now |
| KM-18330 | 2.062 | 1.875 | 24 | $15.90 | Buy Now |
| KM-18329 | 2.125 | 1.937 | 21 | $16.25 | Buy Now |
| KM-18328 | 2.188 | 2.000 | 21 | $16.63 | Buy Now |
| KM-18327 | 2.250 | 2.062 | 21 | $16.98 | Buy Now |
| KM-18317 | 2.312 | 2.125 | 21 | $17.30 | Buy Now |
| KM-18325 | 2.375 | 2.187 | 21 | $17.65 | Buy Now |
| KM-18334 | 2.437 | 2.250 | 21 | $17.98 | Buy Now |
| KM-18323 | 2.500 | 2.312 | 21 | $18.28 | Buy Now |
| KM-18322 | 2.562 | 2.375 | 21 | $18.60 | Buy Now |
| KM-18321 | 2.625 | 2.437 | 21 | $18.90 | Buy Now |
| KM-18320 | 2.688 | 2.500 | 18 | $19.18 | Buy Now |
| KM-18319 | 2.750 | 2.562 | 18 | $19.45 | Buy Now |
| KM-18318 | 2.812 | 2.625 | 18 | $19.73 | Buy Now |
| KM-18343 | 2.875 | 2.687 | 18 | $20.00 | Buy Now |
| KM-18345 | 2.937 | 2.750 | 18 | $20.25 | Buy Now |
| KM-18326 | 3.000 | 2.812 | 18 | $20.53 | Buy Now |
| KM-18351 | 3.062 | 2.875 | 18 | $20.93 | Buy Now |
| KM-18350 | 3.125 | 2.937 | 18 | $21.30 | Buy Now |
| KM-18349 | 3.188 | 3.000 | 18 | $21.68 | Buy Now |
| KM-18348 | 3.250 | 3.062 | 18 | $22.05 | Buy Now |
| KM-18347 | 3.312 | 3.125 | 18 | $22.43 | Buy Now |
| KM-18346 | 3.375 | 3.187 | 15 | $22.80 | Buy Now |
| KM-17499 | 3.437 | 3.250 | 15 | $23.18 | Buy Now |
| KM-17498 | 3.500 | 3.312 | 15 | $23.53 | Buy Now |
| KM-17497 | 3.562 | 3.375 | 15 | $23.90 | Buy Now |
| KM-17496 | 3.625 | 3.437 | 15 | $24.25 | Buy Now |
| KM-17495 | 3.687 | 3.500 | 15 | $24.63 | Buy Now |
| KM-17494 | 3.750 | 3.562 | 15 | $24.98 | Buy Now |
| KM-18344 | 3.812 | 3.625 | 15 | $25.33 | Buy Now |
| KM-17493 | 3.937 | 3.750 | 15 | $26.03 | Buy Now |
| KM-17492 | 4.000 | 3.812 | 15 | $26.38 | Buy Now |
| KM-17491 | 4.062 | 3.875 | 15 | $26.73 | Buy Now |
| KM-17479 | 4.125 | 3.937 | 15 | $27.08 | Buy Now |
| KM-17489 | 4.187 | 4.000 | 15 | $27.40 | Buy Now |
| KM-17500 | 4.250 | 4.062 | 15 | $27.75 | Buy Now |
| KM-17487 | 4.312 | 4.125 | 15 | $28.08 | Buy Now |
| KM-17486 | 4.375 | 4.187 | 12 | $28.43 | Buy Now |
| KM-17485 | 4.437 | 4.250 | 12 | $28.75 | Buy Now |
| KM-17484 | 4.500 | 4.312 | 12 | $29.08 | Buy Now |
| KM-17483 | 4.562 | 4.375 | 12 | $29.40 | Buy Now |
| KM-17482 | 4.625 | 4.438 | 12 | $29.73 | Buy Now |
| KM-17481 | 4.687 | 4.500 | 12 | $30.05 | Buy Now |
| KM-17480 | 4.75 | 4.562 | 12 | $30.38 | Buy Now |
| KM-18335 | 4.812 | 4.625 | 12 | $30.68 | Buy Now |
| KM-17490 | 4.875 | 4.687 | 12 | $31.00 | Buy Now |
| KM-18353 | 4.937 | 4.750 | 12 | $31.30 | Buy Now |
| KM-18342 | 5.000 | 4.812 | 12 | $31.63 | Buy Now |
| KM-18341 | 5.062 | 4.875 | 12 | $32.08 | Buy Now |
| KM-18340 | 5.125 | 4.937 | 12 | $32.53 | Buy Now |
| KM-18339 | 5.187 | 5.000 | 12 | $33.00 | Buy Now |
| KM-18338 | 5.250 | 5.062 | 12 | $33.48 | Buy Now |
| KM-18337 | 5.312 | 5.125 | 12 | $33.93 | Buy Now |
| KM-18336 | 5.375 | 5.187 | 12 | $34.40 | Buy Now |
| KM-17501 | 5.437 | 5.250 | 12 | $34.88 | Buy Now |
| KM-18315 | 5.500 | 5.313 | 12 | $35.33 | Buy Now |
| KM-18287 | 5.562 | 5.375 | 12 | $35.80 | Buy Now |
| KM-17510 | 5.625 | 5.437 | 12 | $36.28 | Buy Now |
| KM-17509 | 5.688 | 5.500 | 12 | $36.75 | Buy Now |
| KM-17508 | 5.750 | 5.562 | 12 | $37.23 | Buy Now |
| KM-17507 | 5.812 | 5.625 | 12 | $37.70 | Buy Now |
| KM-17506 | 5.875 | 5.687 | 9 | $38.18 | Buy Now |
| KM-17505 | 5.938 | 5.750 | 9 | $38.68 | Buy Now |
| KM-17504 | 6.000 | 5.812 | 9 | $39.15 | Buy Now |
| KM-17503 | 6.063 | 5.875 | 9 | $39.63 | Buy Now |
| KM-17468 | 6.125 | 5.937 | 9 | $40.13 | Buy Now |
| KM-18324 | 6.187 | 6.000 | 9 | $40.60 | Buy Now |
| KM-17488 | 6.250 | 6.062 | 9 | $41.08 | Buy Now |
| KM-17455 | 6.312 | 6.125 | 9 | $41.58 | Buy Now |
| KM-17454 | 6.375 | 6.187 | 9 | $42.08 | Buy Now |
| KM-17453 | 6.437 | 6.250 | 9 | $42.55 | Buy Now |
| KM-17452 | 6.50 | 6.312 | 9 | $43.05 | Buy Now |
| KM-17451 | 6.562 | 6.375 | 9 | $43.55 | Buy Now |
| KM-17450 | 6.625 | 6.437 | 9 | $44.05 | Buy Now |
| KM-17449 | 6.688 | 6.500 | 9 | $44.55 | Buy Now |
| KM-17448 | 6.750 | 6.562 | |||
