NNema L and LE Rods Cotton Fabric Reinforced Phenolic
Linen Nema L, LE Rods Cotton Fabric
Reinforced Phenolic - natural (light tan to
brown)
Technical Data Sheet
This grade is composed of a continuous woven cloth
impregnated with a phenolic resin binder. This grade contains a fine weave linen
and, like the canvas phenolic, is known for it's mechanical properties. The
finer weave allows for machining more intricate details than Canvas, like gear
teeth. This grade is not recommended for primary insulation.
NEMA L MIL-I-24768/15- FBI, IEC 60893-3
Type 4 PF CC 305
NEMA LE MIL-I-24768/13 FBE, IEC 60893-3 Type 4 PF CC 305
| Nema L and LE Linen Reinforced Rods | |||
| Part # | Diameter (in.) | Price Per Foot | Order Online |
|---|---|---|---|
| KR-1340 | .062" | $2.56 | Add to Order |
| KR-1341 | .093" | $1.73 | Add to Order |
| KR-1342 | .125" | $1.60 | Add to Order |
| KR-1343 | .156" | $1.67 | Add to Order |
| KR-1344 | .187" | $2.34 | Add to Order |
| KR-1345 | .250" | $2.88 | Add to Order |
| KR-1346 | .312" | $3.56 | Add to Order |
| KR-1347 | .375" | $3.96 | Add to Order |
| KR-1348 | .437" | $5.08 | Add to Order |
| KR-1349 | .500" | $6.46 | Add to Order |
| KR-1350 | .562" | $7.56 | Add to Order |
| KR-1351 | .625" | $8.62 | Add to Order |
| KR-1352 | .750" | $11.57 | Add to Order |
| KR-1353 | .875" | $14.72 | Add to Order |
| KR-1354 | 1.000" | $18.86 | Add to Order |
| KR-1355 | 1.125" | $22.97 | Add to Order |
| KR-1356 | 1.250" | $26.62 | Add to Order |
| KR-1357 | 1.375" | $31.41 | Add to Order |
| KR-1358 | 1.500" | $36.95 | Add to Order |
| KR-1359 | 1.625" | $41.71 | Add to Order |
| KR-1360 | 1.750" | $50.94 | Add to Order |
| KR-1361 | 2.000" | $70.58 | Add to Order |
| KR-1362 | 2.250" | $89.69 | Add to Order |
| KR-1363 | 2.500" | $110.68 | Add to Order |
| KR-1364 | 2.750" | $133.27 | Add to Order |
| KR-1365 | 3.000" | $160.42 | Add to Order |
| KR-1366 | 3.250" | $183.87 | Add to Order |
| KR-1367 | 3.500" | $215.03 | Add to Order |
| KR-1368 | 3.750" | $243.34 | Add to Order |
| KR-1369 | 4.000" | $288.74 | Add to Order |
| KR-1370 | 4.500" | $341.75 | Add to Order |
| KR-1371 | 5.000" | $384.52 | Add to Order |
| KR-1372 | 6.000" | $489.15 | Add to Order |
| Tolerances | |||
Under 1.375" Dia. |
± .001" | ||
1.375" Dia. & Over |
± .003" | ||
| Rev. 03-25, 04-23, 03-23, 12-22 | |||
